ADVR-054 Self Excited 5 Amp Automatic Voltage Regulator

$ 98.42

Category:

Now you can control the sound of the BOV from inside the cabin!

So how much more can you do with a blow-off valve? Well, the Deceptor Pro II takes the ‘Respons’ concept even further...

  • Adjust your BOV venting bias electronically on-the-fly
  • Revised porting to optimise flow and venting bias
  • Compact design fits in most factory valve locations
  • Direct bolt on for many vehicles
  • New bore finishing process ensures a lifetime of reliable operation

Deceptor Pro II features

Direct bolt-on for most vehicles available:

  • Remote proportional venting bias/volume control- from silent to loud or anywhere in between
  • Sleek, compact in-car BOV volume controller with backlit dial
  • End point adjustment to control maximum vent to atmosphere bias setting
  • Volume adjustment mechanism driven by a high-torque geared electric motor
  • Durable, low-friction ger train supported by precision sealed ball-bearing
  • Supplied with all parts and wiring required to have it up and running quickly and easily
MTS ADVR-054 Self Excited 5 Amp Automatic Voltage Regulator For Sale McPherson Controls MTS ADVR-054 Self Excited 5 Amp Automatic Voltage Regulator *Replaces SS-053 & ADVR-053* The MTS ADVR-054 Self Excited 5 Amp Automatic Voltage Regulator is specifically designed to enhance the performance, reliability, and safety of generators, making it an essential component for ensuring uninterrupted power supply in various applications. Order yours today!     Sensing Input (A to C) Average Reading Voltage 170 − 520 Vac Single-phase, 2- wire 220/440 Vac (DIP switch setting) 170 − 260 Vac @ 220 Vac 340 − 520 Vac @ 440 Vac Frequency 50/60 Hz (DIP switch setting)   Input Power (B to C) Voltage 100 − 300 Vac Single-phase, 2-wire Frequency 40 − 60 Hz   Excitation Output (F to F-) 220V Single phase Continuous 63Vdc 5A Intermittent 90Vdc 7A 10Sec Resistance Min.15Ω , Max.100Ω Fuse specification5 x 20mm S505-5A slow blow   Voltage Regulation < /- 0.5% (with 4% engine governing)   Response Time 20ms   Voltage Build-up Residual voltage at AVR terminal > 5 VAC Over Excitation Voltage Protection >35% Input Power Voltage, Delay 5 seconds. This function can be turned off.   External Voltage Adjustment (EXT.VR) /- 3.5% 1 KΩ 1 watt potentiometer   Soft Start Ramp Time 3 seconds /- 10%   Static Power Dissipation 8 watts EMI   Suppression Internal electromagnetic interference filtering   Under Frequency Protection (Factory Setting) At 50 Hz – knee point set at 45 Hz At 60 Hz – knee point set at 55 Hz   Voltage Thermal Drift -40°C to 70 °C?< 3%   Low Frequency Knee Point Thermal Drift -40°C to 70° C?< /- 0.1 Hz   Operating Environment Operating Temperature -40°C to 70 _C Storage Temperature -40°C to 85 _C Relative Humidity < 95% Vibration 5g @ 60 Hz   Dimensions 121.0 (L) x 81.0 (W) x 44.5 (H) mm 4.76” (L) x 3.19” (W) x 1.75” (H) inch
